| Type of Product | Safety Light Curtain |
| Model No | F3SJ-A2470P55 |
| Protection Class | Ip65(Iec60529) |
| Output | PNP Output |
Type of Product |
Safety Light Curtain |
Model No |
F3SJ-A2470P55 |
Protection Class |
Ip65(Iec60529) |
Output |
PNP Output |
Connection Type |
Connector Type (M12, 8-Pin) |
Function |
(Safety-related functions) Start interlock, restart interlock (mute function must be set when using muting function), external relay monitor, muting (lamp disconnection detection, built-in override function. Muting keycap F39-CN6 required), fixed blanking (setting required with setting tool), floating blanking (setting required with setting tool) |
Light Source |
Infrared Led |
Case Material |
Case (Including Metal Parts At Both Ends): Aluminum, Zinc Die-Cast |
Cell Spacing (mm) |
(Optical axis) 50 |
Control Output |
Pnp Transistor Output X 2, Load Current 300Ma Or Less, Residual Voltage 2V Or Less (Excluding The Effect Of Cord Extension), Allowable Capacity Load 2.2Μf, Leakage Current 1Ma Or Less (It May Be Different From (On / Off)) |
Monotaro ID |
46471135 |
Power Supply Voltage |
DC 24 V ± 20% (Ripple P-P10% Or Less) |
Sensor Type |
Type4 Safety Light Curtain |
Series |
F3SJ-A55 series |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting bracket (F39-LJ1 for vertical mounting), intermediate mounting bracket, error mode label, user's manual (CD-ROM) |
Set Contents |
Emitter, Receiver |
Cap Material |
ABS Resin |
Applicable Standard |
Iec61496-1, En61496-1, Ul61496-1 (Type 4 Espe) Iec61496-2, Clc/Ts61496-2, Ul61496-2 (Type 4 Aopd) Iec61508-1 To -3, En61508-1 To -3 (Sil3) Iec13849-1:2006, En Iso13849-1:2008 (Category 4 Ple) Ul508, Ul1998, Can/Csa C22.2 No.14, Can/Csa C22.2 No.0.8 |
Sensor |
Type4 Safety Light Curtain |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Input Voltage (V) |
Test input: ON voltage: Vs-3 to Vs (short circuit current approx. 3.0mA) OFF voltage: 0V to 1 / 2s or open (short circuit current approx. 4.0mA) |
Lens Diameter (Φmm) |
5 |
Specifications |
For safety measures of safety category 4, 3, 2, 1, B |
Remark |
Confirm Delivery Date Each Time |
