| Type of Product | Linear Bush |
| Model No | LMK 8MUU |
| Type | Stainless Steel Type |
| Monotaro ID | 39250312 |
Type of Product |
Linear Bush |
Model No |
LMK 8MUU |
Type |
Stainless Steel Type |
Monotaro ID |
39250312 |
Country of Origin |
Japan |
Maximum Operating Temperature |
80℃ |
Name of Manufacturer/Packer/Importer |
THK Co., Ltd. |
Mounting Hole Diameter (Φmm) |
d1xd2xh：3.4x6.5x3.3 |
Tolerance (mm) |
0 to -0.009 |
Mass (g) |
29 |
Outer Diameter Tolerance (mm) |
0 to -0.011 |
Shape |
Square flange type |
Specifications |
Flange square |
Outer Diameter D (Φmm) |
15 |
Basic load rating Ca (N) |
265 |
Ball Material |
SUS (stainless steel) |
Import Country |
Direct Import from Japan |
Overall Length L |
24 mm (0 to -0.2) |
Special Features |
Sealed on Both Ends of the Outer Cylinder |
Seal Material |
Rubber |
Dimension H (Φmm) |
5 |
Dimension d1 (Φmm) |
32(0 to -0.2) |
Dimension K |
25 mm |
Squareness |
12 μm |
PCD (mm) |
24 |
