Ships within 25 days
View
View
View
View
| Type of Product | Slide Pack Rail |
| Model No | 2FBW3590XR+750L |
| Type | FBW3590XR Type 2 Sliders |
| Monotaro ID | 36718796 |
Type of Product |
Slide Pack Rail |
Model No |
2FBW3590XR+750L |
Type |
FBW3590XR Type 2 Sliders |
Monotaro ID |
36718796 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
THK Co., Ltd. |
Mass (g) |
(Slide rail) 710, (Slider) 250 |
Ball Material |
SUS440C |
Import Country |
Direct Import from Japan |
Dimension B (Φmm) |
0 |
Stroke (mm) |
650 |
Set Contents |
1 slide rail, 2 sliders |
RoHS Directive |
Correspondence |
Dimension L0 (mm) |
750 |
Dimension G |
25 mm |
Case Material |
(Ball case) SPCE |
Clip Material |
SUS304+NBR |
Maximum allowable static load (N) |
(Pa)880、(Pb)200、(Pc)100 |
Dimension N1 (mm) |
7 |
Main Unit Material |
(Slide rail / Mounting plate) SUS304 |
