| Model No | RNFTL1404A3.5S |
| Type of Product | Standard Ball Screw (Unmachined Shaft End) Conveyor Ball Screw R Series (Tube Type Single Flange Nut) RNFTL |
| Seal | With seal |
| Country of Origin | Japan |
Model No |
RNFTL1404A3.5S |
Type of Product |
Standard Ball Screw (Unmachined Shaft End) Conveyor Ball Screw R Series (Tube Type Single Flange Nut) RNFTL |
Seal |
With seal |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Type |
Small / medium lead |
Monotaro ID |
12469741 |
Import Country |
Direct Import from Japan |
Basic static load rating Coa (N) |
10800 |
Basic dynamic load rating Ca (N) |
5370 |
Lead |
4 mm |
Ball diameter (mm) |
(Dw) 2.778 |
Outer Diameter D (Φmm) |
[Screw shaft] 14 |
Effective Number of Turns |
3.5 |
Pitch Circle Diameter |
Ball pitch (dm): 14.5 mm |
Effective Turns Number (circuit) |
1 |
Axial Direction |
[Gap] Maximum 0.1 |
Root Diameter |
[Screw shaft] 11.5 mm |
