Buy Yamaha MGP32X Mixing Console

Note : This Product is not Returnable Rugged, stable, high quality analog mixers with user-friendly construction & aesthetically designed side panels.
PMX-1032FX has 8 MIC/LINE Balanced Mono input channels and 1 STEREO Balanced input channel.
MIC/LINE Balanced Mono inputs with enhanced headroom.
All MIC inputs are through 3 pin F/XLR connectors and All LINE & STEREO inputs are through 6.3mm stereo phone jack sockets.
Four MIC inputs (MIC-1 to MIC-4) are available with 48V phantom supply which can be switched ON/OFF through a common switch.
STEREO Balanced input in two selectable sensitivities of -10dBu & +4dBu.
Separate EFFECT channel is provided for controlling the built-in digital effect processor through a delay selector switch and delay, repeat and level controls.
Each MIC/LINE channel has a GAIN control, 3 band active Equalizer controls, a Pre-fader AUX1 control, a Post-fader
AUX2 /EFX control & a PAN control.
Each Stereo channel has a GAIN control, 2 band active Equalizer controls, AUX1 Pre fader control, AUX2/EFX Post fader control and a BALANCE control.
Channel ON/OFF switch provided on each individual channel. Peak LED for signal clipping indication.
High precision 60mm slide fader on each channel.
Balanced Left & Right Line outputs through M/XLR connectors as well as 6.3mm stereo phone jack sockets.
Easy and accurate monitoring of Left & Right output levels through individual 12 segment LED array.
Two AUX SEND outputs with level controls: one each for monitoring and effects processing applications.
Two stereo AUX RETURN balanced inputs with level controls.
Headphone output with Level Control for output monitoring.
Stereo Tape Playback inputs through L&R RCA sockets provided with ON/OFF switch & level control.
Stereo Record output through L&R RCA sockets.
Operates on 240V 50Hz AC mains.
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg .tg-e3zv{font-weight:bold}
MIC INPUT
Impedance
2kohm Balanced/65dB
LINE INPUT
Impedance/Gain
20kohm Balanced/45dB
STEREO INPUT (L/Mono & R)
Impedance/Gain (-10dBu Input)
10kohm Balanced/14dB
Impedance/Gain (+4dBu Input)
10kohm Balanced/0dB
THD
<0.08%
FREQUENCY RESPONSE
L/R Line Output
25Hz - 20kHz (+0, -1dB)
EQUALIZATION
Bass/Mid/Treble
±12dB at 100Hz/2kHz/10kHz
Clip LED Indication
4 dB prior to true clip
LINE OUTPUT
Nominal/Max Level
4dBu/21dBu (1.22V/9V)
Impedance
600ohm
DELAY SYSTEM
Digital Signal Processing
DELAY RANGE SETTINGS
1: 60-300ms, 2: 300-500ms, 3: 500-650ms
HEADPHONE OUTPUT
200mV at 8ohm, THD <1%
MAXIMUM GAIN
Mic Input to Line Outputs
78dB
Line Input to Line Outputs
58dB
Stereo Input to Line Outputs
28dB (-10dBu Input), 14dB (+4dBu Input)
AUX Send (Pre)
1.4V/100ohm Unbalanced
AUX Send (Post)
2.7V/100ohm Unbalanced
AUX Return (L&R)
150mV/10kohm Balanced
TAPE
Record Output
250mV/600ohm
Playback Input
250mV/1kohm (variable thru’ GAIN control)
Signal To Noise Ratio
>70dB
Power Supply
AC: 220-240V, 50Hz
Dimensions
W465 × H110 × D435mm
Weight
7.7kg
