| Auxiliary Contacts | 1A |
| Type of Product | Magnetic Contactor |
| Model No | SC-05/V Coil AC100V 1A |
| Operation Type | Irreversible |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Auxiliary Contacts |
1A |
Type of Product |
Magnetic Contactor |
Model No |
SC-05/V Coil AC100V 1A |
Operation Type |
Irreversible |
Monotaro ID |
50220274 |
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 13 / (380 to 440 V) 9, resistive load (AC-1): (200 to 240 V) 20 / (380 to 440 V) 20 |
Compatible Motor Capacity |
Three-phase squirrel-cage motor (AC-3): 2.7 kW |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
Rated Carrying Current (A) |
20 |
Length (mm) |
128 |
Width (mm) |
81 |
Thickness (mm) |
53 |
Motor Capacity |
Three-phase squirrel-cage motor (AC-3): 4 kW |
