| Rated Coil Voltage | AC 200 V |
| Auxiliary Contacts | 1A×2 |
| Type of Product | Magnetic Contactor |
| Model No | SC-E4RM Coil AC200V 1A×2 |
Rated Coil Voltage |
AC 200 V |
Auxiliary Contacts |
1A×2 |
Type of Product |
Magnetic Contactor |
Model No |
SC-E4RM Coil AC200V 1A×2 |
Operation Type |
Reversible |
Monotaro ID |
50231824 |
Coil Voltage |
AC 200 V |
Frame |
E4 |
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 80 / (380 to 440 V) 80, resistance load (AC-1): (200 to 240 V) 105 / (380 to 440 V) 105 |
Mounting Screw |
M4 |
Standard |
Compliance standards: IEC 60947-4-1, EN 60947-4-1, VDE 0660, JIS C 8201-4-1<br> Certified standards: UL 60947-4-1, CSA C22.2, Certification body: TUV (EN 60947-4-1) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
Rated Carrying Current (A) |
105 |
Length (mm) |
139 |
Wiring Connections |
Direct wiring compatible |
Width (mm) |
147 |
Applicable Rail Width (mm) |
35 |
Atmosphere |
Low levels of dust, smoke, corrosive gases, flammable gases, steam, and salt. |
Thickness (mm) |
112 |
Installation Altitude (m) |
2000 or less |
Shock Resistance (m/s²) |
50 |
Terminal Fitting Type |
Screw Mounting, 35 mm width Top Hat Rail Mounting |
