Ships within 25 days
View
View
View
View
| Monotaro ID | 70608223 |
| Mass (g) | 105 (without batteries) |
| Type of Product | Coating Thickness Gauge For Both Iron & Non-Iron |
| Accuracy | ≦150μm±5μm >150μm±(3%H+1μ) |
Monotaro ID |
70608223 |
Mass (g) |
105 (without batteries) |
Type of Product |
Coating Thickness Gauge For Both Iron & Non-Iron |
Accuracy |
≦150μm±5μm >150μm±(3%H+1μ) |
Included Components |
Instruction manual, coating sheet x 6, zero adjustment plate (steel) x 1, zero adjustment plate (aluminum) x 1, storage case, strap |
Power Supply |
Alkaline AAA batteries x 2 (sold separately) |
Main Unit Dimensions |
62x27x121.5 mm |
Operating Temperature Range |
-20 to 40℃ |
Target of Measurement |
Ferrous / non-ferrous |
Country of Origin |
CHINA |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Operating Humidity Range |
10 to 95%RH |
Measurement Range (μm) |
0 to 1800 |
Resolution |
0.1(＜100μm), 1(≧100μm) μm |
Function |
1-point measurement, continuous measurement, difference thickness measurement, LCD backlight, auto-off |
Measurement Method |
Electromagnetic type, eddy current type |
Measuring_Accuracy |
Iron base: 0 to 199 μm: ± 10 μm, 200 to 1000 μm: ± (3% + 10 μm), 1001 to 2000 μm: ± (5% + 10 μm) Non-iron metal base: 0 to 199 μm: ± 10 μm, 200 to 1000 μm: ± ( 3% + 10 μm) |
