Ships within 25 days
View
View
View
View
| Monotaro ID | 20929416 |
| Mass (g) | Stopper: 18, Curvature: 72 |
| Type of Product | Curve Measure Thick Wide Silver With Stopper 15 cm Front And Back Same Level 8 Steps Scale |
| Material | Body: ABS resin Screw: Iron Leaf spring: Copper, Curve: Stainless Steel SUS410 |
Monotaro ID |
20929416 |
Mass (g) |
Stopper: 18, Curvature: 72 |
Type of Product |
Curve Measure Thick Wide Silver With Stopper 15 cm Front And Back Same Level 8 Steps Scale |
Material |
Body: ABS resin Screw: Iron Leaf spring: Copper, Curve: Stainless Steel SUS410 |
Thickness (mm) |
2 |
Width (mm) |
20 |
Model No |
12433 |
Color |
Silver |
Accuracy |
Squareness / 100mm, not exceeding ± 0.1mm, length tolerance / overall length ± 0.2mm |
Scale |
Same front and back, 8-stage scale |
Back Scale on Shorter Rule |
Outer scale 7.5cm Inner scale 5cm |
Front Scale on Shorter Rule |
Outer scale 7.5cm Inner scale 5cm |
Front Scale on Longer Rule |
Outer scale 15 cm Inner scale 10 cm |
Back Scale on Longer Rule |
Outer scale 15 cm Inner scale 10 cm |
Shape |
Same thickness |
Shorter Rule |
85 mm |
Longer Rule |
170 mm |
Scale Range |
(Long branch) outside 15cm, inside 10cm, (short branch) outside 7.5cm, inside 5cm |
Angular accuracy |
Stopper: Less than 0.2 per 100 mm |
Dimensions, Width x Thickness (mm) |
20x2.0 mm |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Shinwa Measurement Co., Ltd. |
Import Country |
Direct Import from Japan |
Measurement Range (cm) |
0 - 15 |
Squareness (mm) |
(Scale side) 150 does not exceed 0.15 |
Dimension (mm) |
75x40x14 |
