| Country of Origin | Japan |
| Display | 4.3 inch TFT color LCD (WQVGA: 480 x 272 dots) |
| Type of Product | Midi Logger |
| Vibration Resistance | Equivalent to Class A automotive parts |
Country of Origin |
Japan |
Display |
4.3 inch TFT color LCD (WQVGA: 480 x 272 dots) |
Type of Product |
Midi Logger |
Vibration Resistance |
Equivalent to Class A automotive parts |
Function |
Trigger/alarm function, calculation, data storage function, data backup function, checksum function, recording function, scaling function, recording function |
No. of Channels |
[Input] Analog / 10ch, pulse / 4ch or logic / 4ch |
Measurement Range |
Voltage: 20, 50, 100, 200, 500mV, 1, 2, 5, 10, 20, 50V, 100V, 1-5V FS / Temperature: Thermocouple (K, J, E, T, R, S, B, N, C (old W: WRe5-26)) / Humidity: 0 to 100% (dedicated humidity sensor B-530 required) |
Model No |
GL260 |
Monotaro ID |
63154929 |
RoHS Directive |
Correspondence |
Dimension (mm) |
About 188 x 117 x 42 |
Import Country |
Direct Import from Japan |
Memory |
Main unit: (internal) approximately 8GB, (external) 1 SD card slot (maximum 32GB) |
Name of Manufacturer/Packer/Importer |
Graphtec |
Mass (g) |
Approx. 500 (excluding AC adapter and battery) |
Specifications |
PC software: Included as standard Power supply: (AC power adapter) AC 100-240V/50-60Hz, (DC drive) DC 8.5-24V (dedicated cable: B-514 required), battery pack (dedicated battery: B-573 required) / [External sampling input] Maximum input frequency: 100kHz / Time error: 1μs or less / [Number of analog input channels] 10ch / TIME/DIV: 1s to 24h, PC I/F: USB2.0 (high speed), Wireless LAN (when option is installed) |
Dimension (WxDxH) |
Approximately 188x117x42 mm (excluding protrusions) |
Operation Environment |
0 to 45 ° C, 5 to 85% RH (0 to 40 ° C when battery driven, 15 to 35 ° C when charged) |
External Output |
Alarm output (4 channels), output format: open collector output (5V pull-up resistor 10kΩ) |
Display Items |
Analog waveform/past data display during measurement/digital value/split display |
External Input |
Trigger input (1 channel) or external sampling input (1 channel), logic input (4 channels) or pulse input (4 channels) / Input voltage range: 0 to +24V (single-wire grounded input) / Input signal: Non-voltage contact (a contact, b contact, NO, NC), open collector, voltage input |
Analog Input |
Screw type terminal |
Power Consumption (VA) |
36 or less (AC adapter used, LCD on, battery pack charged, AC100V) |
Sampling Cycle |
10ms to 1h (10ms to 50ms: voltage only, limited number of channels), external |
Supported OS |
PC software: Windows11/10 |
Measurement Modes |
Rotation speed mode/integration mode/instantaneous mode |
Number of Pulses |
Maximum input frequency: 50kHz, Maximum count: 50kC/sampling (16-bit counter) |
LCD Size |
4.3 inch TFT color LCD (WQVGA: 480 x 272 dots) |
RTC Power Battery |
DC7.2V (2875mAh) (battery pack option) |
Power Input (DC-V) |
8.5 to 24 |
Memory System |
[Built-in memory] GL260: Approx. 8 GB (built-in, fixed) / [External memory slot] SD card slot SD memory card: SDHC compatible, up to approx. 32 GB memory available / [Memory contents] Main unit setting conditions, measurement data, screen copy |
Trigger |
[Trigger repeat] Off, On / [Trigger type] Start: Starts data recording when a trigger is met, Stop: Stops data recording when a trigger is met / [Trigger settings] Start: Off, Level, Alarm, External, Time, Day of the week, Fixed time, Stop: Off, Level, Alarm, External, Time, Day of the week, Fixed time |
AC Power Adapter (V) |
100 to 240/50 to 60Hz |
