| Insulation Resistance | DC250V (20MΩ or more with mega / between cases) |
| Monotaro ID | 22204963 |
| Operating Force (N) | Low operating force |
| Type of Product | Microswitch |
Insulation Resistance |
DC250V (20MΩ or more with mega / between cases) |
Monotaro ID |
22204963 |
Operating Force (N) |
Low operating force |
Type of Product |
Microswitch |
Case Material |
GF reinforced PBT (black) |
Type |
Without rubber seal |
Model No |
MS1B-JE |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Operation Ambient Temperature (°C) |
-20 to 85 |
Pretravel (PT) |
0.15 to 0.4 mm |
Withstand voltage (V / min) |
AC1000 (between live parts and case) |
Output Current (mA) |
15MAX |
Operations |
ON-OFF |
Cable |
3-core Φ2.8x1m, black |
Stroke (mm) |
1 |
Power Supply Voltage (V) |
DC 5 to 24 |
Allowable Operating Frequency (times/min) |
60 or less |
Repeatability (mm) |
±0.002 |
Operation Mechanism |
Lever type |
Current Consumption (mA) |
12MAX |
Output Specifications |
NPN open collector (OFF when approaching) |
Seal Material |
Nitrile rubber |
