| Insulation Resistance | DC250V (20MΩ or more with mega / between cases) |
| Ambient Humidity to Use | 20 to 95%RH |
| Monotaro ID | 22204857 |
| Operating Force (N) | 0.5 |
Insulation Resistance |
DC250V (20MΩ or more with mega / between cases) |
Ambient Humidity to Use |
20 to 95%RH |
Monotaro ID |
22204857 |
Operating Force (N) |
0.5 |
Type of Product |
Microswitch |
Case Material |
GF reinforced PBT |
Model No |
MR2A |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Movement Differential (Max.) |
0.1mm or less |
Operation Ambient Temperature (°C) |
-20 to 85 (no condensation) |
Pretravel (PT) |
0.15 to 0.4 mm |
Withstand voltage (V / min) |
AC1000 (between live parts and case) |
Output Current (mA) |
15MAX |
Operations |
OFF-ON |
Stroke (mm) |
2 |
Power Supply Voltage (V) |
DC 5 to 24 |
Allowable Operating Frequency (times/min) |
60 or less |
Repeatability (mm) |
±0.001 |
Current Consumption (mA) |
12MAX |
Output Specifications |
NPN open collector (ON when approaching) |
