| Actuator Type | Leaf lever |
| Contact Material | Silver-Nickel Alloy + Au Clad |
| Monotaro ID | 48189034 |
| Operating Force (N) | (Max)0.98 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Actuator Type |
Leaf lever |
Contact Material |
Silver-Nickel Alloy + Au Clad |
Monotaro ID |
48189034 |
Operating Force (N) |
(Max)0.98 |
Type of Product |
Micro Switch |
Contact Type |
Switching Type |
Model No |
ABJ361841 |
Country of Origin |
Japan |
Mechanical Life |
10^6Operations |
Import Country |
Direct Import from Japan |
Protection Class |
IP67 |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Movement Differential (Max.) |
(Max) 1 mm |
Over travel |
(Minimum) 2.5 mm |
Pack of |
50 Pcs |
Mounting |
Mounting hole size: 3 mm |
Contact Resistance (ohm) |
150 Or Less (Dc 6 To 8V 0.1A Voltage Drop Method) |
Insulation Resistance (MOhm) |
over 100 |
Rated Resistance Load Current (A) |
AC125V/DC30V：0.1 |
Operation Ambient Temperature (°C) |
-40-85 |
Terminal Shape |
Bottom lead wire |
Maximum switching frequency (times / minute) |
120 |
Rated Primary Current (A) |
0.1 |
Mounting Hole (mm) |
3 (Leaf Lever Type Only) |
Operating position OP (mm) |
16.0±2.0 |
Mounting Screw Spacing (mm) |
13 |
Pretravel (PT) |
(maximum) 6 mm |
