| Type of Product | Spline Micrometer SPM |
| Model No | SPM-75MX |
| Series | 331 |
| Country of Origin | Japan |
Type of Product |
Spline Micrometer SPM |
Model No |
SPM-75MX |
Series |
331 |
Country of Origin |
Japan |
Monotaro ID |
18483842 |
RoHS Directive |
Correspondence |
Included Components |
1 reference rod, 1 spanner (no.301336) |
Minimum Reading (mm) |
0.001 mm |
Type |
Digimatic (LCD) |
Flatness (μm) |
0.3 μm |
Parallelism (μm) |
2 |
Measuring Surface (mm) |
Φ3×10 |
Position Detection Method |
Electromagnetic Induction Rotary Encoder |
Dimensions C (mm) |
17.5 |
Dimensions B (mm) |
60 |
Function |
Origin setting function (ABS measurement system), zero setting function, hold function, measurement data output function, auto power ON/OFF function, error alarm, function lock function |
Power Supply |
One Button-Type Silver Oxide Battery SR44 (No. 938882) Is Included As Standard (The Button-Type Silver Oxide Battery Included As Standard Is For Monitor Use) |
Dimension L (mm) |
50 |
Protection Class |
IP65 |
Trusco Part No. |
772-9456 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Measuring_Range |
50 - 75 mm |
Specifications |
Measurement data wireless system, U-WAVE-TM transmission unit (IP67 type) 264-622 (buzzer type) 264-623, U-WAVE-TMB transmission unit (U-WAVE fit Bluetooth(R) version) (IP type) 264-626 (buzzer type) 264-627, U-WAVE-TM/TMB connection unit (IP67/buzzer type common) 02AZF310 |
Dimensions A (mm) |
11.5 |
Maximum Permissible Error (μm) |
J MPE：±2 |
