Ships within 25 days
View
View
View
View
| Type of Product | 150 Series Micrometer Head (Standard Type) |
| Model No | MHN2-25 |
| Series | 150 |
| Country of Origin | Japan |
Type of Product |
150 Series Micrometer Head (Standard Type) |
Model No |
MHN2-25 |
Series |
150 |
Country of Origin |
Japan |
Tip Shape |
Plane |
Monotaro ID |
1996574 |
RoHS Directive |
Correspondence |
Minimum Reading (mm) |
0.01 mm |
Type |
With ratchet |
Surface Treatment |
(Scale) Hard chrome plating |
Hardness |
Measurement surface: 90HRA or higher |
Stem Shapes |
Stem with nut |
Trusco Part No. |
105-4422 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Measuring_Range |
0 - 25 mm |
Specifications |
Measuring surface: Lapped |
Mass (g) |
100 |
Product Code |
150-191 |
Maximum Permissible Error (μm) |
J MPE：±2 |
Material (Measuring Surface) |
Carbide Tip |
Recommended Thickness (mm) |
11.5 |
Mass of Main Unit (g) |
100 |
