| Type of Product | Soft Touch Micro |
| Model No | CLM2-20QMX |
| Series | 227 |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Soft Touch Micro |
Model No |
CLM2-20QMX |
Series |
227 |
Country of Origin |
Japan |
Monotaro ID |
44061956 |
Measuring Force (N) |
2 to 10 (variable) [2, 4, 6, 8, 10] |
Included Components |
1 standard stick, 1 flathead screwdriver (No. 210183) |
Minimum Reading (mm) |
0.001 mm |
Type |
Variable measuring force digital micrometer |
Flatness (μm) |
0.3 μm |
Dimensions B (mm) |
36 |
Function |
Variable measuring force function, origin set function, zero set function, hold function, function lock function, auto power ON / OFF function, measurement data output function, error alarm |
Power Supply |
One Button-Type Silver Oxide Battery SR44 (No. 938882) Is Included As Standard (The Button-Type Silver Oxide Battery Included As Standard Is For Monitor Use) |
Dimension L (mm) |
10 |
Operating Temperature Range |
5 - 40°C |
Quantization Error |
± 1 Count |
Output |
Measurement data output |
Dimensions D (mm) |
10 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Measuring_Range |
12 to 20 mm |
Specifications |
, Error relative to set measuring force: ±(0.4+set measuring force/10)N, Variation in measuring force: Within 0.4N (value when used in horizontal position ±3° or less) |
Mass (g) |
425 |
Dimensions A (mm) |
8.5 |
References |
Measurement position: Horizontal position only (spindle inclination within ±3° is recommended) |
Dimensions E (mm) |
22 |
