| Type of Product | Small Ball Bearings / Miniature Ball Bearings |
| Model No | 635VV |
| Material | High Carbon Steel |
| Monotaro ID | 6181987 |
Type of Product |
Small Ball Bearings / Miniature Ball Bearings |
Model No |
635VV |
Material |
High Carbon Steel |
Monotaro ID |
6181987 |
Basic load rating Cr (N) |
2340 |
Load direction |
Radial |
Rolling element material |
High Carbon Chromium Bearing Steel |
JIS grade |
0 |
Width B1 (mm) |
6 |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Chamfer Dimension r1 (mm) |
0.3 (minimum) |
Shield Shape |
Non-contact seal type on both sides |
Race ring shape |
Deep Groove Ball Bearings |
Basic load rating Cor (N) |
885 |
Outer Diameter D (Φmm) |
19 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Inner Diameter (mm) |
5 |
Bearing Number |
600 |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
32000 |
