| Type of Product | Miniature Ball Bearing Contact Type Sealed Bearing |
| Model No | 609DD |
| Material | High Carbon Steel |
| Monotaro ID | 38400205 |
Type of Product |
Miniature Ball Bearing Contact Type Sealed Bearing |
Model No |
609DD |
Material |
High Carbon Steel |
Monotaro ID |
38400205 |
Basic load rating Cr (N) |
3350 |
Load direction |
Radial |
Rolling element material |
High Carbon Chromium Bearing Steel |
JIS grade |
0 |
Width B1 (mm) |
7 |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Chamfer Dimension r1 (mm) |
(Minimum) 0.3 |
Shield Shape |
Double contact seal type |
Race ring shape |
Deep Groove Ball Bearings |
Basic load rating Cor (N) |
1430 |
Outer Diameter D (Φmm) |
24 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Inner Diameter (mm) |
9 |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
24000 |
Nominal No. |
609 |
