| Type of Product | Stainless Miniature Ball Bearing / Small Diameter Ball Bearing (Open Type) |
| Model No | F-693 |
| Material | Stainless Steel |
| Monotaro ID | 9143906 |
Type of Product |
Stainless Miniature Ball Bearing / Small Diameter Ball Bearing (Open Type) |
Model No |
F-693 |
Material |
Stainless Steel |
Monotaro ID |
9143906 |
Load direction |
Radial |
Rolling element material |
Stainless Steel |
JIS grade |
0 |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Deep Groove Ball Bearings |
Flange |
Without flange |
Outer Diameter D (Φmm) |
8 |
Basic static load rating Cor (N) |
180 |
Width B (mm) |
3 |
Basic dynamic load rating Cr (N) |
760 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Chamfer Dimension r (mm) |
0.15 min |
Permissible Speed (min-1) Oil Lubrication |
63000 |
Inner Diameter (mm) |
3 |
Permissible Speed (min-1) Grease Lubrication |
54000 |
