| Type of Product | Single Board Computer |
| Model No | RASPi4-SDST8GB |
| Monotaro ID | 13164335 |
| Import Country | Direct Import from Japan |
Type of Product |
Single Board Computer |
Model No |
RASPi4-SDST8GB |
Monotaro ID |
13164335 |
Import Country |
Direct Import from Japan |
Output |
Video: 2xHDMI 2.0 Type D (Micro HDMI) video/audio sockets<br> Composite video (PAL/NTSC) output: Φ3.5mm 4-pole jack Display interface: DSI |
Memory |
(LPDDR4)8GB |
Power Supply |
5 V 3 A (USB Type C) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kyoritsu Electronics Industry Co., Ltd. |
Bluetooth |
5.0/BLE |
Storage |
microSD memory card (SDIO) |
Size |
56(W)x85(D)x17(H) mm |
Audio Output |
Stereo: Φ3.5mm 4-pole jack HDMI: Shared with video output I2S pin header |
Suitable CPU |
64bit 1.5 GHz quad core ARM Cortex-A72 |
Specifications |
GPIO: 40-pin 2.54mm pin header, 26 GPIOs, 3.3V 16mA, UART, I2C, SPI, I2S, PWM, 5V (depending on power supply)<br> 3.3V 50mA (total including GPIO) GPU: Broadcom VideoCore VI 3D graphics core SoC: Broadcom BCM2711 Ethernet: 10/100/1000 Base-T RJ45 socket (Broadcom BCM54213PE) Camera interface: CSI |
Main Unit |
8GB version |
Maximum Power Consumption (w) |
About 15 |
Number of Video Outputs |
4K：2 |
RoHS Directive |
Correspondence |
USB Ports |
2(USB3.0)+2(USB2.0) |
Wi-Fi |
IEEE 802.11 b / g / n / ac 2.4 / 5 GHz dual band |
