| Type of Product | Temperature/Humidity Sensor |
| Model No | THD-D1-T |
| Sensor | Temperature sensor |
| Monotaro ID | 75621230 |
Type of Product |
Temperature/Humidity Sensor |
Model No |
THD-D1-T |
Sensor |
Temperature sensor |
Monotaro ID |
75621230 |
Protection Class |
IP65 (IEC standard / excluding sensor part) |
Country of Origin |
Japan |
Temperature |
DPt100Ω Resistance (Temperature coefficient: 3850 ppm/℃) |
Import Country |
Direct Import from Japan |
Output Type |
RS485 communication output |
Display Type |
No display type |
Standard |
CE, UKCA, K, EAL, RoHS |
Name of Manufacturer/Packer/Importer |
Autonics |
Length (mm) |
[Sensor rod] 100 |
Temperature Accuracy |
± 1.0 ℃ (room temperature range), ≤ ±0.8 ℃ |
Specifications |
Duct-mounted type |
Operation Ambient Temperature (°C) |
-20 to 60°C, Storage: -20 to 60°C (Do not freeze or condense) |
Cord |
Cord pull-out type, 2m, Φ4mm, 4 cores |
RoHS Directive |
Correspondence |
Power Supply Voltage (V) |
DC 24 |
Humidity Measurement Range (%) |
0.0–99.9%RH (However, due to its protective structure, THD-R requires caution at humidity levels above 90%RH) |
Temperature Measurement Range |
-19.9 to 60.0℃ |
Humidity Accuracy |
Typical ±2%RH / (10–90%RH, room temperature range) / ≤ ±2.5%RH |
