| Type of Product | I / O catcher (clamp type current ON / OFF sensor) |
| Model No | SE-CS001A |
| Cable specifications | Single electric wire |
| Monotaro ID | 52384825 |
Type of Product |
I / O catcher (clamp type current ON / OFF sensor) |
Model No |
SE-CS001A |
Cable specifications |
Single electric wire |
Monotaro ID |
52384825 |
Applicable Wire Diameter (Φmm) |
Target detection: 5.0 (max) <1 turn> /2.7 (max) <2 turns> |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Power Consumption (W) |
120m (at 12V power supply) / 240m (at 240m power supply) |
Name of Manufacturer/Packer/Importer |
Inaba Electric Industry Co., Ltd. |
Main Unit Material |
66 nylon (housing) |
Specifications |
Detection threshold: 10mA ± 5mA (including effects of geomagnetism and ambient temperature) |
Ambient Temperature (℃) |
0 to 60 (operation) /-20 to 70 (storage) |
Hysteresis |
1mA(Typ) |
Power Supply Voltage (V) |
DC12 to 24 |
Cable Type |
Drawer: Φ4X3c (02.mm2X3) 2m |
Responsiveness |
200ms or less for both ON / OFF output |
