| Type of Product | ID Sensor Unit |
| Model No | CS1W-V680C11 |
| Power Supply | (External) unnecessary |
| Type | RFID system V680V series |
Type of Product |
ID Sensor Unit |
Model No |
CS1W-V680C11 |
Power Supply |
(External) unnecessary |
Type |
RFID system V680V series |
Connector |
V680 series amplifiers and antennas |
Monotaro ID |
39035744 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Applicable Standard |
cULus, EC Directive |
No. of Channels |
(Occupied) 10CH |
Unit Type |
High-performance I / O unit |
Current Consumption (A) |
0.26 (internal 5 V), 0.13 (internal 24 V / 26 V) |
Command |
Light Command |
Self-Diagnosis Function |
CPU watchdog timer Communication error detection with ID tag Antenna power supply error |
No. of Connections |
(Antenna / Amplifier) 1 unit |
Data Packet Rate |
160 bytes / scan (between CPU unit and ID sensor unit) |
