| Type of Product | Process Input Unit |
| Model No | CS1W-PTS03 |
| Suitable For | (PLC) CS series |
| Response Time | 0.5s (input time from 0% to 90% for step input) |
Type of Product |
Process Input Unit |
Model No |
CS1W-PTS03 |
Suitable For |
(PLC) CS series |
Response Time |
0.5s (input time from 0% to 90% for step input) |
Type |
Insulated RTD input unit |
Monotaro ID |
46386611 |
Mass (g) |
450 or less |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Resolution |
1/4096 (for full span of internal range) |
Display Part |
Front / 3 LEDs (during normal operation, abnormalities detected by the unit, abnormalities detected by the CPU unit) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Applicable Standard |
cULus (Class II Div2 hazardous area certified product), EC Directive |
Function |
Disconnection detection, measured value averaging processing (input filter), measured value alarm, change rate alarm, change rate calculation, change rate alarm |
Accuracy (%) |
±0.2% (to the full span of the internal range) or 0.2°C, whichever is greater For the set input range: by the ratio of the internal range span to the set input range span or 0.2°C, whichever is greater |
Unit Type |
CS Series High-performance I / O unit |
Structure |
Base mounting type, single size |
Outer Dimensions |
35 x 130 x 126 mm (excluding base unit height) |
Insulation Type |
Between each channel and between the input terminal and PLC signal: Insulated by a transformer |
Current Consumption (A) |
0.15(5 V - 26 V) |
Number of Input Points |
4 points |
Measurement Method |
3-wire type |
Time |
CPU unit uptake maximum / conversion cycle + CPU unit 1 cycle, effect time on CPU unit cycle time / 0.3ms |
