| Type of Product | Smart Sensor Laser Type Sensor |
| Model No | ZX-LD40-0.2M |
| Shape | (Beam) spot |
| Type | Spot beam |
Type of Product |
Smart Sensor Laser Type Sensor |
Model No |
ZX-LD40-0.2M |
Shape |
(Beam) spot |
Type |
Spot beam |
Cable Length (m) |
0.2 |
Monotaro ID |
46452646 |
Mass (g) |
About 150 |
Protection Class |
IEC standard IP50 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Beam Diameter |
Φ50 μm |
Resolution |
2 μm |
Measurement Range |
±10 |
Temperature Characteristics |
0.03%F.S./℃ |
Lens Material |
Glass |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Connection Type |
Connector relay |
Case Material |
Polybutylene terephthalate |
Detection Distance (mm) |
40 |
Included Components |
Instruction manual, laser warning label (English) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
Cover Material |
Aluminum |
Operation Ambient Temperature (°C) |
Operating: 0 to 50, Storage: -15 to 60 (but do not freeze or condense) |
Ambient Illumination to Use (Lx) |
Light receiving surface illumination Incandescent lamp: 3000 or less |
