| Type of Product | Smart Sensor Linear Proximity Type |
| Model No | ZX-EV04-S |
| Shape | Flat |
| Type | Discriminating displacement sensor |
Type of Product |
Smart Sensor Linear Proximity Type |
Model No |
ZX-EV04-S |
Shape |
Flat |
Type |
Discriminating displacement sensor |
Cable Length (m) |
2 |
Monotaro ID |
46453032 |
Protection Class |
(Sensor head) IEC60529 standard IP67 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Resolution |
1.6 μm |
Measurement Range |
0 to 4 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Connection Type |
Connector relay type |
Case Material |
Zinc (nickel plated) (sensor head) |
Standard Sensing Object (mm) |
Iron (S50C) 60 x 60 x 3 |
Included Components |
Preamplifier mounting bracket (ZX-XBE1), instruction manual |
Vibration Resistance (Destruction) |
10 to 55 Hz, 1.5 mm double amplitude, 2h in each direction of X, Y, Z |
Specifications |
With protective spiral tube |
Insulation Resistance (MOhm) |
50 or more (DC 500 mega) |
Operation Ambient Temperature (°C) |
During operation: -10 to 60 (but no freezing or condensation), Storage: -20 to 70 (but do not freeze or condense) |
Material (Detection Surface) |
Heat-resistant ABS (sensor head) |
Locator Material |
Possible: Magnetic metals (non-magnetic metals have different measurement ranges and linearity.) |
