| Type of Product | Smart Sensor |
| Model No | ZX-TDS10-VL |
| Shape | Long range |
| Type | Air lift / Air push |
Type of Product |
Smart Sensor |
Model No |
ZX-TDS10-VL |
Shape |
Long range |
Type |
Air lift / Air push |
Monotaro ID |
39113584 |
Mass (g) |
About 100 |
Protection Class |
(Head) IP50, (Preamplifier) IP40 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Resolution |
0.4 μm |
Measurement Range |
10 mm |
Temperature Characteristics |
(Sensor head) 0.01% FS/°C (Preamplifier) 0.01% FS/°C |
Linearity |
±0.04% F.S. |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Connection Type |
Connector relay type (between sensor head and preamplifier: 2m, between preamplifier and connector: 0.2m) |
Included Components |
Preamplifier mounting bracket (ZX-XBT1) Right angle adapter |
Shock Resistance (m/s²) |
150 6 directions 3 times each (up and down, left and right, front and back) |
Vibration Resistance (Destruction) |
10 to 55 Hz, 0.35 mm single amplitude, 50 min each in X, Y, and Z directions |
Specifications |
Compatible with Vacuum retract (VR) / air push (AP) |
Ambient Humidity (% RH) |
Operation and storage: 35 to 85 each (with no condensation) |
Ambient Temperature (℃) |
Operating: 0 to +50 Storage: -10 to +60 (with no icing or condensation) |
Mechanical Life |
10 Million Times Or More |
Material (Mounting Bracket) |
stainless steel |
Dimension (Φmm) |
8 |
Movable Range |
10.5 mm |
Measuring Force (N) |
About 0.09 to 1.41 |
