| Type of Product | Fiber Unit |
| Model No | E32-A02 5M |
| Shape | Flat side view |
| Type | Fiber unit |
Type of Product |
Fiber Unit |
Model No |
E32-A02 5M |
Shape |
Flat side view |
Type |
Fiber unit |
Monotaro ID |
39047906 |
Mass (g) |
Approx. 100 (packed) |
Protection Class |
IEC60529 standard IP50 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Fiber Length (m) |
5 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Fiber cutter (E39-F4) |
Shock Resistance (m/s²) |
500 X, Y, Z directions 3 times |
Vibration Resistance (Destruction) |
10-55 Hz, multiple width 1.5mm, X, Y, Z directions 2h |
Specifications |
Application specific type (liquid level) |
Tensile Strength (N) |
9.8 or less |
Bending Radius (mm) |
4 or more |
Ambient Humidity (% RH) |
In use: 35 to 85 Storage: 35 to 95 (no condensation) |
Ambient Temperature (℃) |
During use and storage: -40 to 70 (with no icing or condensation) |
Detection Target |
Liquid surface |
