| Type of Product | Small Laser Sensor Type E3Nc-L Series Amplifier Unit |
| Model No | E3NC-LA24 |
| Control Output | Load power supply voltage: DC30V or less, open collector output type, load current: 100mA or less when 1 to 3 units are connected, 20mA or less when 4 or more units are connected (residual voltage load current less than 10mA: 1V or less, load current 10 to 100mA: 2V or less) off state current: 0.1mA or less |
| Response Time | Fastest mode (SHS): Operation and recovery: 80μs each, High speed mode (HS): Operation and recovery: 250μs each, Standard mode (Stnd: Operation and recovery: 1ms each, Giga power mode (GIGA): Operation and recovery: 16ms each |
Type of Product |
Small Laser Sensor Type E3Nc-L Series Amplifier Unit |
Model No |
E3NC-LA24 |
Control Output |
Load power supply voltage: DC30V or less, open collector output type, load current: 100mA or less when 1 to 3 units are connected, 20mA or less when 4 or more units are connected (residual voltage load current less than 10mA: 1V or less, load current 10 to 100mA: 2V or less) off state current: 0.1mA or less |
Response Time |
Fastest mode (SHS): Operation and recovery: 80μs each, High speed mode (HS): Operation and recovery: 250μs each, Standard mode (Stnd: Operation and recovery: 1ms each, Giga power mode (GIGA): Operation and recovery: 16ms each |
Monotaro ID |
66470188 |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Connection Type |
M8 connector type |
Power Supply Voltage |
DC 10-30 V including ripple (pp) 10% |
Output Format |
NPN output |
Indicator Lamp |
7 segment display (sub digital display: green + main digital display: white), display direction: normal/reverse display switchable, OUT indicator (orange), L/D indicator (orange), ST indicator (blue), DPC indicator (green), OUT selection indicator (orange) (2 outputs only) |
Protection Circuit |
Power supply reverse connection protection, output short circuit protection, output reverse connection protection |
Input / Output Options |
1 output + 1 input |
Power Consumption (mW) |
[Power supply voltage 24V] Normal mode: 1560 or less (current consumption 65mA or less), Eco function ON: 1320 or less (current consumption 55mA or less), Eco function LO: 1440 or less (current consumption 60mA or less) |
No. of Connections |
Maximum: 30 units |
Sensitivity Adjustments |
Smart tuning [2-point tuning/full auto tuning/positioning tuning/maximum sensitivity tuning/power tuning/percent tuning (-99% to +99%)] or manual adjustment |
