| Type of Product | Inductive Sensor Barrel Type |
| Model No | XS230AANAL2 |
| Monotaro ID | 48727483 |
| Country of Origin | Japan |
Type of Product |
Inductive Sensor Barrel Type |
Model No |
XS230AANAL2 |
Monotaro ID |
48727483 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Type |
cable |
Output Type |
NPN-NO |
Housing Material |
PPS |
Name of Manufacturer/Packer/Importer |
TELEMECANIQUE SENSORS |
Thread Size |
M30x1.5 |
Length (mm) |
60 |
Switching Current |
200 mA |
Specifications |
Food Industry Sensors. Telemecanique OsiSense Inductive Sensors are sensors specially designed for the food, beverage and pharmaceutical industries. . From freezing temperature of -25 °C to disinfection temperature of +85 °C Cylindrical stainless steel and plastic body Connector according to IEC 60529, IP67 Sensor with cable according to IP68 (double insulation) DIN 40050 IP69K with cable and connector Type) Cable or quick disconnect connector Tamper-proof laser ID non-embedded part number; 181-629 181-629, 181-691 181-691, 181-720 181-720, 181-641 181- The 641 is a 2-wire type and requires an M12 connector (product number: 695-6877 695-6877). |
Maximum DC Voltage |
58 V |
Power Supply Voltage (V) |
12 to 48 DC |
Main Unit Type |
Barrel shape |
Detection Range (mm) |
22 |
Type of Sign |
Non-embedded type |
Short Circuit Overload Protection |
Yes |
