Ships within 19 days
Rated Output Current (A)
Model No
View
View
View
View
| Storage Temperature | -25 to 65℃ |
| Type of Product | Switching Power Supply |
| Model No | S8VS-09024S-F |
| Rated Output Current (A) | 3.75 A |
Storage Temperature |
-25 to 65℃ |
Type of Product |
Switching Power Supply |
Model No |
S8VS-09024S-F |
Rated Output Current (A) |
3.75 A |
Monotaro ID |
39096391 |
Rated Input Voltage (V) |
100-240 AC V |
Shape |
Directly on DIN Rail |
Mass (g) |
490 or less |
Function |
Undervoltage detection indication: None |
Type |
No display monitor Standard type |
Ambient Humidity to Use |
25-85% (Storage humidity 25-90%) |
Alarm Output |
Sink (emitter COM) |
Recommended Timing to Replace |
None |
Series |
S8VS Series |
Structure |
Type with cover |
Output Voltage (V) |
DC 24 |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Outer Dimensions |
50x115x120.3 mm |
Capacity (W) |
90 |
Connection Type |
Terminal block |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 60 (no condensation or freezing) |
Specifications |
UL Class2 output (UL1310): Compliant |
Insulation Resistance (MOhm) |
Between 100 or more (collective output, collective alarm output) and (collective input, ground [earth]) at 500 V DC |
