Ships within 19 days
Model No
View
View
View
View
| Mounting Type | With Cover/DIN rail mount |
| Storage Temperature | -25 to 75 ℃ (no condensation or freezing) |
| Type of Product | Switching Power Supply |
| Model No | S8FS-G60024CD-WR |
Mounting Type |
With Cover/DIN rail mount |
Storage Temperature |
-25 to 75 ℃ (no condensation or freezing) |
Type of Product |
Switching Power Supply |
Model No |
S8FS-G60024CD-WR |
Power Factor |
0.9 or more |
Rated Power |
600 W |
Rated Output Voltage (V) |
DC24 |
Terminal Shape |
Screw Terminal Block |
Rated Output Current (A) |
27 |
Monotaro ID |
66518637 |
Rated Input Voltage (V) |
AC 100 to 240 |
Shape |
With cover |
Mass (g) |
1050 |
Function |
Parallel operation function, remote control function |
Vibration Resistance |
10 to 55Hz Maximum 4.5G Single amplitude 0.375 mm 2h each in 3 directions |
Inrush current (A) |
AC 100/200 V input: 14/28typ. (25℃, cold start) |
Safety Standard |
UL 508 (Listing: Connector type, not with remote control function)・UL 508 (Recognition: with remote control function only)・UL 62368-1 (Recognition, OVCⅡ[≦3000m], Pol2)・CSA C22.2 No.107.1 (Connector type, not with remote control function)・CSA C22.2 No.62368-1 (Connector type, not with remote control function)・EN 62477-1 (OVCⅢ〔≦2000m〕, OVCⅡ〔2000＜and≦3000m〕, Pol2)・EN/IEC 62368-1 (OVCⅡ〔≦3000m〕, Pol2)・Complies with EN/IEC 61558-2-16・Complies with PELV (EN/IEC 60204-1)・RCM (EN61000-6-4)・BIS: IS 13252(Part 1) |
Load Fluctuation |
Static: 1% or less |
Input Fluctuation |
Static: 0.5% or less |
Series |
S8FS-G Series |
Standard |
EMS: EN 61204-3 high severity levels/SEMI F47-0706 (AC 200 V input) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN rail mounting |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to 70 (Temperature derating) (No condensation or freezing) |
Shock Resistance (m/s²) |
150 (3 times in 6 directions) |
Insulation Resistance (MOhm) |
100 or more, DC500 V (between all output terminals) and (all input terminals) |
