| Type of Product | Power Supply |
| Model No | PH100A280-12 |
| Size | Industry standard: 1/4 brick |
| Rated Output Voltage (V) | DC 12 |
Type of Product |
Power Supply |
Model No |
PH100A280-12 |
Size |
Industry standard: 1/4 brick |
Rated Output Voltage (V) |
DC 12 |
Terminal Shape |
DIP |
Monotaro ID |
49729393 |
Rated Input Voltage (V) |
DC 280 |
Input Voltage Range (V) |
DC 200 to 425 |
Shape |
On board |
Mass (g) |
55 |
Type |
Power module |
No. Of Output |
1 |
Output Current (A) |
(Maximum) 8.4 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Width (mm) |
37.200000000000003 |
Name of Manufacturer/Packer/Importer |
TDK-LAMBDA |
Length (mm) |
58.3 |
Maximum output power |
100 W |
Specifications |
With base plate, ORing circuit, parallel operation |
Options |
Standard |
Output Voltage Adjustment Range |
9.6 to 13.2 V |
Height (mm) |
12.7 |
