| Type of Product | Sensor Connector |
| Model No | CNE-S04-YW |
| Material | Body: PC/ABS (UL94V-0), Terminals: C5210 (Gold 0.2μm), Case: PC (UL94-V0) |
| RoHS Directive | Correspondence |
Type of Product |
Sensor Connector |
Model No |
CNE-S04-YW |
Material |
Body: PC/ABS (UL94V-0), Terminals: C5210 (Gold 0.2μm), Case: PC (UL94-V0) |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
AC/DC 32 |
Monotaro ID |
78052917 |
Rated Current (A) |
3 |
Standard |
CE, UKCA, RoHS |
No. of Pole |
4 |
Color |
yellow |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Autonics |
Pack of |
50 Pcs |
Outer Diameter (mm) |
Φ1.0 to 1.2 |
Insertion Force |
1.96 N(200 gf)/pin or less |
Operation Ambient Temperature (°C) |
1A power supply: -20 to 85°C, 2A power supply: -20 to 75°C, 3A power supply: -20 to 60°C (no freezing or condensation) |
Power Supply Voltage |
250VAC to |
Wire Sheath Outer Diameter (mm) |
1.0 to 1.2 |
AWG |
AWG24 to 26 |
Nominal Sectional Area (mm²) |
0.13 to 0.21 |
Extraction Force |
0.49 N(50 gf)/pin or more |
Holding Power |
[Terminal] 1.4kgf or more |
