| Type of Product | Soldering Type Dip Connector |
| Model No | 57-10240 |
| Material | Copper alloy / Au plating , Brass / Ni plating (Applicable to 20 types), Vinyl chloride (applicable to 30 and 60 types) |
| Type | Plug for unit connection, internal plug |
Type of Product |
Soldering Type Dip Connector |
Model No |
57-10240 |
Material |
Copper alloy / Au plating , Brass / Ni plating (Applicable to 20 types), Vinyl chloride (applicable to 30 and 60 types) |
Type |
Plug for unit connection, internal plug |
Rated Voltage (V) |
AC 500(r, m.s, ) |
Monotaro ID |
46523944 |
Rated Current (A) |
5 / Contact |
Shape |
Solder cup type |
Material (Shell) / Finish |
Brass or steel / Ni plating |
Withstand voltage (V) |
AC 1.200 (RMS) for 1 minute |
Country of Origin |
Japan |
Operating Temperature Range |
-55 to +105℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fujikura (formerly DDK/Daiichi Electronics Industries) |
Insulator Material |
DAP resin (UL94V-0) / blue |
Insulation Resistance (MOhm) |
1000 or more at 500 V DC |
Contact Resistance (ohm) |
5 or less at DC 5 Amp |
Applicable Wire Range Twisted Wire (mm²) |
0.2 (conductor cross-sectional area) or AWG24 or less |
Applicable Wire range |
0.65 mm (conductor diameter) or AWG22 or less |
