Ships within 25 days
View
View
View
View
| Type of Product | Pin Header |
| Model No | FSD-42050-06TB |
| Monotaro ID | 55350244 |
| Contact Resistance | 20 mΩ Max (DC 100 mA) |
Type of Product |
Pin Header |
Model No |
FSD-42050-06TB |
Monotaro ID |
55350244 |
Contact Resistance |
20 mΩ Max (DC 100 mA) |
Surface Treatment |
Contact/Ni base Gold flash |
No. Of Pin |
12 |
Contact Material |
Phosphor bronze |
Country of Origin |
Japan |
Operating Temperature Range |
-40 to +105℃ |
No. of Row |
Double Row |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Hirosugi Instruments Co., Ltd. |
Pack of |
200 Pcs |
Insulation Resistance (MOhm) |
Min. 5000 mΩ (DC 500 V) |
Body Color |
Black |
Main Unit Material |
Nylon |
Current Capacity (Amps) |
3 |
Pitch Size |
2.54 mm |
RoHS Directive (10 Substances Compliant) |
Correspondence |
Combustion Efficency |
Body/UL94V-0 (material) |
Thermal Deformation Temperature |
Body/1.80 mPA...290℃ |
