| Type of Product | JL04V Series Plug |
| Connection Method | Solder |
| Model No | JL04V-6A20-15SE-R |
| Type | Socket insert |
Type of Product |
JL04V Series Plug |
Connection Method |
Solder |
Model No |
JL04V-6A20-15SE-R |
Type |
Socket insert |
Rated Voltage (V) |
(Pollution degree 3) AC250 / (Pollution degree 2) AC500 |
Monotaro ID |
41193941 |
Rated Current (A) |
23 or less |
No. of Pole |
7 |
Connection Type |
Screw |
Shape |
Straight |
Country of Origin |
Japan |
Operating Temperature Range |
-55 to +125°C |
Import Country |
Direct Import from Japan |
Finish Type |
(Contact part) Silver plating |
Name of Manufacturer/Packer/Importer |
Japan Aviation Electronics Industry, Ltd. |
Shell Size |
20 |
Connector Shape |
Single block type |
Pack of |
1 Pcs |
Contact Size |
#12 |
Specifications |
Socket insert |
Compatible Cable |
3.5 or less |
Insulation_Resistance (MΩ) |
1000 or more |
Contact Shape |
Female |
Sequence Number |
20-15 |
Waterproof Specifications |
IP67 class when mated |
Matching Connector |
JL04V-2E, JL04V-2A |
