| Type of Product | Connector Pin |
| Model No | S11B-XASK-1(LF)(SN) |
| Withstand Voltage | 1000 VAC for 1 minute |
| Material | (Pin) Copper alloy, (Base) Nylon 66 / UL94V-0 with glass |
Type of Product |
Connector Pin |
Model No |
S11B-XASK-1(LF)(SN) |
Withstand Voltage |
1000 VAC for 1 minute |
Material |
(Pin) Copper alloy, (Base) Nylon 66 / UL94V-0 with glass |
Type |
Side type |
Rated Voltage (V) |
250 V AC/DC |
Monotaro ID |
34954062 |
Rated Current (A) |
3 AC / DC, (When using AWG # 22) |
Standard |
Recognised E 60389 Certified LR 20812 R9851220 |
No. of Pole |
11 |
Surface Treatment |
Copper-undercoated tin plating (reflow treatment) |
Color |
Natural (ivory) |
Suitable For |
xAP-※V |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to +85℃ (including temperature rise during energization) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Japan Solderless Terminals Mfg. Co., Ltd. |
Dimension A (Φmm) |
25 |
Pack of |
10 Pcs |
Insulation Resistance (MOhm) |
1000 or more |
Contact Resistance (ohm) |
Initial: 10 mΩ or less After environmental test: 20 mΩ or less |
Dimension B (Φmm) |
30 |
Specifications |
RoHS compliant product |
Suitable Circuit Board Thickness (mm) |
1.6 |
Wire Crimping Range (AWG#) |
28 to 20 |
