| Type of Product | Relay Connector |
| Model No | 5557-18R-210 |
| Withstand Voltage | 1500V AC / 1 minute |
| Type | housing |
Type of Product |
Relay Connector |
Model No |
5557-18R-210 |
Withstand Voltage |
1500V AC / 1 minute |
Type |
housing |
Rated Voltage (V) |
600 (maximum) |
Monotaro ID |
8561664 |
Rated Current (A) |
9 (maximum) |
Standard |
UL file No .: E29179CSA File No .: LR19980 |
No. of Pole |
18 |
Housing Material |
Nylon 66 |
Suitable For |
Plug: 5559 <br> Terminal: 5556 |
Country of Origin |
Japan |
Operating Temperature Range |
-40 to +105 <br> (Including temperature rise due to energization) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Molex |
Cell Spacing (mm) |
4.2 |
Dimension A (Φmm) |
39 |
Pack of |
10 Pcs |
Insulation Resistance (MOhm) |
1000 or more |
Contact Resistance (ohm) |
less than 10 |
Dimension B (Φmm) |
33.6 |
Flame Retardance |
UL94V-0 |
