| Type of Product | Joint Plug/Socket |
| Model No | XS2R-D422-1 |
| Withstand Voltage | AC 1550 (Leakage current 1mA or less) |
| Material | Contact/brass Fixtures/brass Contact block/PA resin (UL94V-O) O-ring/rubber |
Type of Product |
Joint Plug/Socket |
Model No |
XS2R-D422-1 |
Withstand Voltage |
AC 1550 (Leakage current 1mA or less) |
Material |
Contact/brass Fixtures/brass Contact block/PA resin (UL94V-O) O-ring/rubber |
Type |
Waterproof Connector |
Rated Voltage (V) |
DC 125 |
Monotaro ID |
34813231 |
Rated Current (A) |
3 |
No. of Pole |
4 poles |
Surface Treatment |
Contact/Ni base gold plating 0.4m Fixture/Ni plating |
Color |
Contact block / light gray |
Protection Class |
IP67(IEC529) |
Country of Origin |
JAPAN |
Operating Temperature Range |
-25 to 70 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Supply |
For DC |
Category |
Adaptors Plugs & socket |
