| Type of Product | Round Waterproof Connector (M12) With Cable |
| Model No | XS2H-A421-A90-F |
| Type | For AC |
| Rated Voltage (V) | DC 36 |
Type of Product |
Round Waterproof Connector (M12) With Cable |
Model No |
XS2H-A421-A90-F |
Type |
For AC |
Rated Voltage (V) |
DC 36 |
Monotaro ID |
46682711 |
Rated Current (A) |
1.5 A |
No. of Pole |
4 Pole |
Contact Material |
Brass |
Operating Humidity Range |
20 to 85%Rh |
Shape |
Straight |
Cover Material |
Soft PBT (UL94V-0) |
Protection Class |
IP67 |
Material (O-ring) |
Rubber |
Cable Length (m) |
0.3 m |
Connector |
One side connector |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Cable Direction |
Straight |
Cable |
Flame retardant, robot cable |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
1000 or more (at 500 V DC) |
Contact Resistance (ohm) |
40 mΩ or less (DC 20 mV mΩ or less, 100 mA or less) |
Number of Cores x Sectional Area (mm²) |
4x0.5 |
