| Type of Product | Din Socket Sequence Connector |
| Model No | XC7A-9042 |
| Total Insertion Force | Number of poles x 1N or less |
| Withstand Voltage | AC 1000 V/1 min (leak current 1 mA or less) |
Type of Product |
Din Socket Sequence Connector |
Model No |
XC7A-9042 |
Total Insertion Force |
Number of poles x 1N or less |
Withstand Voltage |
AC 1000 V/1 min (leak current 1 mA or less) |
Rated Voltage (V) |
AC 300 |
Monotaro ID |
46588412 |
Rated Current (A) |
2 |
No. of Pole |
90 |
Housing Material |
Glass-filled PBT resin (UL94/V-0) |
Shape |
Plug L-shaped terminal |
Country of Origin |
JAPAN |
Operating Temperature Range |
-55 to 125 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
DIP L-shaped terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Dimension A (Φmm) |
126.8 |
Insulation Resistance (MOhm) |
10 ⁶ or more (at DC 100 V) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
121 |
Dimension C |
111.76 mm |
Dimension d |
121.9 mm |
Dimension F (Φmm) |
118.2 |
Dimension E (Φmm) |
117 mm |
Specifications |
●Sequence terminal position: None ●Material (contact terminal part): Brass |
