Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | Hard Metric Connector |
| Model No | XC8F-0551L-NN |
| Total Insertion Force | (Contact) No. of poles x 0.75 N or less (Ground) No. of poles x 1.00 N or less |
| Type | Type B plug |
Type of Product |
Hard Metric Connector |
Model No |
XC8F-0551L-NN |
Total Insertion Force |
(Contact) No. of poles x 0.75 N or less (Ground) No. of poles x 1.00 N or less |
Type |
Type B plug |
Rated Voltage (V) |
AC500 |
Monotaro ID |
46591185 |
Rated Current (A) |
1 |
No. of Pole |
55 |
Housing Material |
LCP resin with glass (UL94 V-0) / gray |
Contact Material |
(Contact part) Phosphor bronze / nickel base socket Gold plating, Plug Gold palladium plating, (Terminal part) Phosphor bronze / nickel plating |
Series |
XC8 Series |
Country of Origin |
Germany |
Operating Temperature Range |
-55 to +125 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
L-shaped terminal (without top shield plate) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Part No |
64-3391-21 |
Withstand voltage (V / min) |
AC 750 (leakage current 1 mA or less) |
Insulation Resistance (MOhm) |
10 ⁴ or more (at 100 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Specifications |
No shield plate, no pegs |
