| Type of Product | Hard Metric Connector |
| Model No | XC8C-0951S-0 |
| Total Insertion Force | (Contact) No. of poles x 0.75 N or less (Ground) No. of poles x 1.00 N or less |
| Type | Type B plug |
Type of Product |
Hard Metric Connector |
Model No |
XC8C-0951S-0 |
Total Insertion Force |
(Contact) No. of poles x 0.75 N or less (Ground) No. of poles x 1.00 N or less |
Type |
Type B plug |
Rated Voltage (V) |
AC 500 |
Monotaro ID |
46590862 |
Rated Current (A) |
1 |
No. of Pole |
95 |
Housing Material |
PC resin with glass (UL94 V-0) / Gray |
Contact Material |
(Contact part) Phosphor bronze / nickel base socket Gold plating, Plug Gold palladium plating, (Terminal part) Phosphor bronze / nickel plating |
Country of Origin |
GERMANY |
Operating Temperature Range |
-55 to +125 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Part No |
64-3390-94 |
Withstand voltage (V / min) |
AC 750 (leakage current 1 mA or less) |
Dimension A (Φmm) |
36 |
Insulation Resistance (MOhm) |
10 ⁴ or more (at 100 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
38 |
Specifications |
No pegs |
Terminal Length |
3.7 mm |
