Ships within 19 days
Cable Length (m)
Model No
View
View
View
View
| Type of Product | Round waterproof connector (M12) Connector with cable Socket One Side Connector |
| Model No | XS2F-A421-EB0-F |
| Type | For AC |
| Rated Voltage (V) | AC 250 |
Type of Product |
Round waterproof connector (M12) Connector with cable Socket One Side Connector |
Model No |
XS2F-A421-EB0-F |
Type |
For AC |
Rated Voltage (V) |
AC 250 |
Monotaro ID |
46681476 |
Rated Current (A) |
1.5 |
No. of Pole |
4 |
Contact Material |
Phosphor bronze |
Operating Humidity Range |
20 to 85%Rh |
Color |
Contact Block: Light Gray |
Cover Material |
Soft PBT (UL94V-0) |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Cable Length (m) |
3 m |
Series |
XS2 Series |
Connector |
One-Sided Connector |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Cable |
Flame-retardant, bending-resistant cable |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Tensile Strength |
Assembly part fixed: 98N / 15s |
Cable Holding Strength (N/15s) |
Outer diameter Φ6: 98, Outer diameter Φ4 to Φ5: 49, Outer diameter: Φ3: 29 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
Connector: 40 mΩ or less (20 mV mΩ or less, 100 mA or less) |
Number of Cores x Sectional Area (mm²) |
2x0.5 |
