| Type of Product | Round Waterproof Connector (M8/S8) With Cable |
| Model No | XS3W-S422-402-R |
| Type | Waterproof connector |
| Rated Voltage (V) | DC125 |
Type of Product |
Round Waterproof Connector (M8/S8) With Cable |
Model No |
XS3W-S422-402-R |
Type |
Waterproof connector |
Rated Voltage (V) |
DC125 |
Monotaro ID |
46684251 |
Rated Current (A) |
1 A |
No. of Pole |
4 Pole |
Contact Material |
Phosphor bronze |
Cover Material |
Soft PBT (UL94V-0) |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Material (fixing bracket) |
Brass / nickel plated or SUS316L |
Cable Length (m) |
2 |
Series |
XS3W Series |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Cable Direction |
L type / L type |
Cable |
Robot cable |
Connection |
1 brown 2 white 3 blue 4 black |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Fixing Type |
Snap-in type |
Tensile Strength |
Cable: 49N / 15s |
Installation |
S8 type |
Withstand voltage (V / min) |
(Connector part) AC 1000 (Leakage current 1 mA or less) |
Insulation Resistance (MOhm) |
1000 or more (at DC 500 V) |
Contact Resistance (ohm) |
(Connector) 40 mΩ or Less (DC 20 mV mΩ or Less, 100 mA mΩ or Less) |
