| Type of Product | Round Waterproof Connector Assembled Connector Plug |
| Model No | XS2G-D4S6 |
| Type | (Crimp Type/Solder Type) |
| Rated Voltage (V) | AC/DC 250 V |
Type of Product |
Round Waterproof Connector Assembled Connector Plug |
Model No |
XS2G-D4S6 |
Type |
(Crimp Type/Solder Type) |
Rated Voltage (V) |
AC/DC 250 V |
Monotaro ID |
46682666 |
Rated Current (A) |
4 |
No. of Pole |
4 |
Surface Treatment |
Contact/Ni base gold plating 0.4 μm Fixture/Ni plating |
Contact Material |
Brass |
Connection Type |
Screw connection |
Color |
Contact block / light gray |
Cover Material |
PBT resin (UL94V-O) |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Series |
XS2 Series |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to 70℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Fixing Type |
M12 screw type |
Power Supply |
For DC |
Cap Material |
PBT resin (UL94V-O) |
Ambient Humidity (% RH) |
20 to 85 |
Insulation Resistance (MOhm) |
1000 or more (at 500 V DC) |
Contact Resistance (ohm) |
40 mΩ or Less (Connector part: 20mV mΩ or Less, 100 mA mΩ or Less) |
Suitable Cable Outer Dia. (Φmm) |
For Φ3 (Φ3 to Φ4) |
