Ships within 19 days
Model No
View
View
View
View
| Type of Product | Round Waterproof Connector (M8/S8) With Cable |
| Model No | XS3F-E422-410-A |
| Withstand Voltage | Connector: AC1000V 1min (Leakage current 1 mA or less) |
| Rated Voltage (V) | DC125 |
Type of Product |
Round Waterproof Connector (M8/S8) With Cable |
Model No |
XS3F-E422-410-A |
Withstand Voltage |
Connector: AC1000V 1min (Leakage current 1 mA or less) |
Rated Voltage (V) |
DC125 |
Monotaro ID |
46683865 |
Rated Current (A) |
1 A |
No. of Pole |
4 Pole |
Contact Material |
Phosphor bronze / nickel base gold plating |
Shape |
L-shaped |
Cover Material |
Soft PBT |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Cable Length (m) |
10 m |
Country of Origin |
Japan |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Cable Direction |
L-shaped |
Cable |
Standard Cable Φ4 4-Core x 0.2 mm² (0.12 / 18) |
Connection |
Brown white blue black |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Tensile Strength |
Cable: 49N / 15s |
Installation |
M8 type |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
Connector: 40 mΩ or less (DC 20 mV mΩ or less, 100 mA or less) |
