| Type of Product | Din Style Connector |
| Model No | XC5F-0132-2 |
| Total Insertion Force | Number of poles x 0.59 N or less |
| Type | Socket |
Type of Product |
Din Style Connector |
Model No |
XC5F-0132-2 |
Total Insertion Force |
Number of poles x 0.59 N or less |
Type |
Socket |
Rated Voltage (V) |
AC 300 |
Monotaro ID |
46587073 |
Rated Current (A) |
2 |
No. of Pole |
100 |
Housing Material |
PBT resin with glass (UL94 V-0) / gray |
Contact Material |
(Contact part) Phosphor bronze / nickel base gold plating (0.15 μm), (Terminal part) Phosphor bronze / nickel base tin plating (2 μm) |
Country of Origin |
JAPAN |
Operating Temperature Range |
-55 to +125 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
DIP L-shaped terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Withstand voltage (V / min) |
AC 1000 (leakage current 1 mA or less) |
Dimension A (Φmm) |
144.6 |
Insulation Resistance (MOhm) |
10 ⁶ or more (at 100 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
130.7 |
Dimension C |
124.46 mm |
Dimension d |
139.7 mm |
Dimension E (Φmm) |
128.7 mm |
