| Type of Product | Discrete Wire IDC Connector |
| Total Insertion Force | 50x1.96N or less |
| Withstand Voltage | 500 VAC, 1 min (leakage current 1 mA or less) |
| Type | Polarity guide type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Discrete Wire IDC Connector |
Total Insertion Force |
50x1.96N or less |
Withstand Voltage |
500 VAC, 1 min (leakage current 1 mA or less) |
Type |
Polarity guide type |
Rated Voltage (V) |
AC300 |
Monotaro ID |
8593776 |
Rated Current (A) |
AWG28：1、AWG26：2 |
Standard |
RoHS directive, UL standard (File No.E103202) |
No. of Pole |
50-Pole |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Suitable Wire |
AWG28, 26 (using UL-1007) , wire outer diameter: Φ1.1-1.3 mm, core wire configuration: 7 stranded wires |
Insertion / Removal Durability (Times) |
50 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Dimension A (Φmm) |
φ68.1 mm |
Manufacturer Part Number |
XG5M-5035-N |
Insulation Resistance (MOhm) |
10³ or more (at 500 VDC) |
Polarity Guide |
1 |
Spark Plug Type |
Type XG4A (flat cable connector long lock), type XG4A (flat cable connector lock lever rear mounting), type XG4A (flat cable connector two-tier stacking), type XG4E (flat cable connector pressure welding type plug long lock), type XG4C (flat) Cable connector box type plug), XG8W / XG8B (2 rows of original plugs), XG4A / XG4C should use the same number of polar slots as the number of polar guides of XG5M-N. |
Contact No. |
2 |
Operation Ambient Temperature (°C) |
-55 to +85 (no freezing at low temperatures) |
Single Removal Force |
0.29 N or more (with □ 0.64mm test gauge) |
Contact Resistance (ohm) |
20 or less (20mV or less, 100mA or less) |
Dimension B (Φmm) |
φ60.96 mm |
